LAB GRUPPEN FP-13000 2 CHANNEL AMPLIFIER
[PRICED PER UNIT - 2 AVAILABLE AT TIME OF LISTING]
Listing last update on November 03, 2020 - Viewed 198 times

THE FP 13000 IS THE FLAGSHIP MODEL OF THE FP+ SERIES. AT THE CORE OF THE FP 13000'S PERFORMANCE IS A BREAKTHROUGH ADVANCE IN LAB.GRUPPEN'S PATENTED CLASS TD OUTPUT STAGE, AN AMPLIFIER TOPOLOGY THAT APPROACHES THE EXCEPTIONAL EFFICIENCY OF CLASS D WHILE RETAINING THE SONIC PURITY OF PROVEN CLASS AB DESIGNS. FURTHER CONTRIBUTING TO THE REMARKABLE EFFICIENCY OF THE FP 13000 IS A REGULATED SWITCH MODE POWER SUPPLY (R.SMPS), WHICH GIVES THE ADDED BENEFIT OF STABILIZING RAIL VOLTAGES TO THE OUTPUT EVEN WITH WIDE FLUCTUATIONS OF MAINS VOLTAGE. A HIGHLY REFINED AND UPDATED CIRCUIT LAYOUT OPTIMIZES THE INTERACTION OF R.SMPS AND CLASS TD TO PRODUCE THE EXTRAORDINARY POWER DENSITY OF THE FP 13000.

THE FP13000 IS SHIPPED WITH A NOMADLINK® NETWORK INTERFACE AS STANDARD. IN CONJUNCTION WITH DEVICECONTROL PC SOFTWARE, NOMADLINK® ALLOWS MONITORING OF ALL KEY AMPLIFIER PARAMETERS AND REMOTE CONTROL OF POWER ON/OFF, CHANNEL MUTES, AND CHANNEL SOLO FUNCTIONS. (NOMADLINK® REQUIRES THE SEPARATE NLB 60E NETWORK BRIDGE.)

 NUMBER OF CHANNELS 2

MAX. TOTAL OUTPUT BOTH CHANNELS DRIVEN 13000 W

MAX. OUTPUT VOLTAGE PER CHANNEL 195 VPEAK

 MAX. OUTPUT CURRENT PER CHANNEL 58 ARMS

 MAX. OUTPUT POWER 2 OHMS 4 OHMS 8 OHMS 16 OHMS

 PER CH. (BOTH CH.’S DRIVEN) 6500 W 4400 W 2350 W 1200 W

BRIDGED - 3) 13000 W 8800 W 4700
