ID # 68743 CURRENT CATEGORY - AMPLIFIER
LAB GRUPPEN PLM 10000Q
[PRICED PER UNIT - 1 AVAILABLE AT TIME OF LISTING]
Listing last update on June 04, 2013 - Viewed 187 times
Click on thumbnail to enlarge
Asking Price:
SOLD
[PRICED PER UNIT - 1 AVAILABLE AT TIME OF LISTING]
PLM 10000Q POWERED LOUDSPEAKER MANAGEMENT SYSTEM
THE TWO- INPUT, FOUR- OUTPUT PLM 10000Q SEAMLESSLY INTEGRATES NET- WORKED DIGITAL SIGNAL DISTRIBUTION, DRIVE PROCESSING, POWER AMPLIFICA- TION, AND LOAD VERIFICATION PLUS PERFORMANCE MONITORING IN A SINGLE HARDWARE UNIT AND UNIFIED SOFTWARE CONTROLLER. THIS NEW APPROACH, DESIGNATED POWERED LOUDSPEAKER MANAGEMENT (PLM), IS A COHESIVE BLEND OF LAKEï½® PROCESSING AND LAB.GRUPPEN POWER. AS A COMPLETE SYSTEM, THE PLM 10000Q AFFORDS SIGNIFICANT BENEFITS WHEN COMPARED TO CONVENTIONAL APPROACHES UTILIZING SEPARATE COMPONENTS.
LAB.GRUPPEN TECHNOLOGY
â–¸ 2350 W PER CHANNEL @ 2 OHMS**
â–¸ 2300WPERCHANNEL@4OHMS**
â–¸ 2UCHASSISWEIGHINGONLY13.5KG(30LBS)
â–¸ CLASS TDï½® OUTPUT STAGE
â–¸ REGULATEDSWITCHMODEPOWERSUPPLY(R.SMPSTM)
â–¸ COPPER-FINNED INTERCOOLERï½® WITH TRANSVERSE-MOUNTED OUTPUT DEVICES
â–¸ FULL SUITE OF PROTECTION AND FAULT MONITORING FEATURES
â–¸ COMPREHENSIVE LOUDSPEAKER PRESET DATABASE
â–¸ LOADLIBRARYTM LOAD æ“¢INGERPRINT (IDENTITY AND CHARACTERISTICS) DATA
â–¸ COMPREHENSIVE LOADSMARTTM LOAD VERIFICATION AND SPEAKERSAFETM CON- TINUOUS LOUDSPEAKER PERFORMANCE MONITORING
â–¸ DANTETM LOW-LATENCY DIGITAL NETWORK INCLUDED AS STANDARD
â–¸ COMPATIBLE WITH LAKE LM 26, DOLBYï½® LAKE PROCESSOR AND OTHER LEGACY LAKE DEVICES
â–¸ PRIMARYANDSECONDARYNETWORKCONNECTIONS â–¸ DIGITALLYCONTROLLEDå°¿MPLIFIERGAINå°¿DJUSTABLEIN0.1DBSTEPSFROM22
TO 44 DB
â–¸ DIGITALOUTPUTATTENUATIONIN0.25DBSTEPSFROM-INFTO0DB
â–¸ BINDING POST OR NEUTRIKï½® SPEAKONï½® (1 X NLT8, 2 X NLT4) POWER OUTPUT CONNECTORS
â–¸ DIGITALLY IMPLEMENTED, ZERO-OVERSHOOT INTER-SAMPLE VOLTAGE PEAK LIMITING (ISVPLTM) ADJUSTABLE IN 0.1 V STEPS FROM 17.8 TO 153 V
â–¸ POWERAVERAGELIMITER(PAL)
â–¸ HIGH-BRIGHTNESS FRONT-PANEL LCD DISPLAY
â–¸ MOISTURE RESISTANT SILICONE TOUCHPAD FOR FRONT-PANEL DISPLAY MODE SELECTION AND MENU NAVIGATION
LAKE PROCESSING TECHNOLOGY
â–¸ RAISEDCOSINEEQUALIZATIONTM
â–¸ LINEARPHASEANDCLASSICALCROSSOVERS
â–¸ LIMITERMAXTM PEAK AND RMS LIMITERS
â–¸ ISO-FLOATTM GROUND ISOLATION
â–¸ SUPERMODULECAPABILITY
â–¸ INTEGRATION OF THIRD PARTY FREQUENCY MEASUREMENT AND ANALYSIS SYSTEM VIA THE LAKE ANALYZER BRIDGE
â–¸ ANALOGANDAESDIGITALINPUTSWITHLOOP-THRUOUTPUTS
â–¸ AUTO-SELECTINPUTROUTERFORALLINPUTSWITHUSERDEFINABLEPRIORITIES
| Additional Details | |
| ID#: | 68743 |
| Listing Type: |
Standard
|
| Model: | PLM10000Q |
| Manufacturer: | LAB.GRUPPEN |
| Condition: | SUPERB (8-9) |
| Shipping Info: | 0.00 lbs., |
| Seller's Location: | CA, USA |
| Updated: | June 04, 2013 |
| M.S.R.P.: | $0.00 |
| Asking Price: | SOLD |
