CREST CENTURY LMX 52 CHANNEL CONSOLE
[PRICED PER UNIT - 1 AVAILABLE AT TIME OF LISTING]
Listing last update on February 01, 2010 - Viewed 321 times

CREST LMX (YOM: ?) (S#: TBD) SUPERB (8-9)

FEATURES: FREQUENCY RESPONSE
+0.0, -0.5DB, 20HZ TO 20 KHZ (REFERENCED TO 1KHZ)
TOTAL HARMONIC DISTORTION
(MIC INPUT TO GROUP OUTPUT)
20HZ TO 20 KHZ AT +15DBU <0.01%
PHASE RESPONSE
20Hz to 20 kHz +20°, -20°
NOISE (22Hz to 22kHz)
Mic EIN (150W, 60dB gain) -129 dBu
Group Output Noise (40 inputs) - 80 dBu
CROSSTALK (Measured at 1kHz)
Channel Mute >100 DB
CHANNEL FADER ATTENUATION > 85 DB
INPUT/OUTPUT IMPEDANCES
MIC INPUT 4K½ BALANCED
LINE INPUT >10K½ BALANCED
OUTPUTS 120½ BALANCED
INPUT/OUTPUT LEVELS (0VU = +4 DBU, 1.23V RMS)
MIC INPUT SENSITIVITY + 4 TO -62 DBU
LINE INPUT SENSITIVITY + 12 TO -38 DBU
INPUT INSERTION POINT LEVEL + 4 DBU
OUTPUT INSERTION POINT LEVEL + 4 DBU
NOMINAL OUTPUT LEVEL + 4 DBU
MAXIMUM BALANCED OUTPUT LEVEL +28 DBU


EXTRAS: CASE AND 2 POWER SUPPLIES

MODIFICATIONS: NO

HISTORY: USED ON ONLY ONE BROADWAY SHOW.

COMMENTS: EXCELLENT CONDITION WITH A FEW SCRATCHES AND MARKS. ALL KNOBS THERE AND WORKING. 100% WORKING CONDITION. USED ON ONLY ONE BROADWAY SHOW

THIS UNIT WAS NEVER TOURED
