CARVIN DCM3800L AMP
[PRICED PER UNIT - 1 AVAILABLE AT TIME OF LISTING]
Listing last update on October 22, 2014 - Viewed 231 times

PLEASE NOTE: AS THIS LISTING IS BELOW THE  PRICE RANGE OF OUR NORMAL SALES PROGRAM, THIS IS ITEM CAN ONLY BE PURCHASED THROUGH OUR  DIRECT TO BUYER/SELLER PROGRAM.

SOUNDBROKER.COM WILL ONLY REFER THE CONTACT INFORMATION OF THE SELLER TO VIP LOYALTY CLUB MEMBERS AND THIS CAN ONLY BE PURCHASED DIRECTLY FROM THE SELLER.

THE PRICE SHOWN IS THE EXACT AMOUNT THE SELLER IS ASKING.

JUST REMEMBER WHEN GOING DIRECT THESE 4 MAIN POINTS (AS DESCRIBED IN DETAIL IN OUR MEMBERSHIP AGREEMENT):

1) BUYER AND SELLER BEWARE AND YOU AGREE TO HOLD SOUNDBROKER.COM HARMLESS

2) THE AGGREGATE VALUE OF THE GEAR MUST BE $2,500.00 OR LESS

3) IF EITHER PARTY WANTS SOUNDBROKER.COM TO HOLD THE MONEY, BOTH PARTIES MUST AGREE AND THERE IS A 3% FEE

4) SOUNDBROKER.COM HAS RIGHT TO OFFER A QUOTE FOR SHIPPING SERVICES (OPTIONAL)

5) IF YOU WISH TO PURCHASE THIS ITEM FROM SOUNDBROKER.COM RATHER THAN GO DIRECT, WE WILL ADD A $150 SERVICE FEE OR 15% WHICHEVER IS GREATER. (OPTIONAL)

CALL OUR OFFICE AT 702-736-3003 OR CLICK HERE FOR THE DETAILS


CARVIN DCML3800L (YOM: ?) (S#: TBD) LIKE NEW (9-10)

FEATURES: FEATURES
- BUILT-IN LIMITERS HELP PROTECT DRIVERS
- LED INDICATORS: POWER, CLIP, 3 LEVELS, PROTECT, BRIDGE
- BALANCED XLR AND 1/4" INPUTS
- TWIST-LOCK OUTPUT CONNECTORS
- 3RD TWIST-LOCK CONNECTOR FOR BRIDGING
- HEAVY-DUTY OUTPUT BINDING POSTS
- REAR SWITCHES: BRIDGING, LIMITER, CHANNEL PARALLELING, GROUND LIFT
- RECESSED KNOBS OFFER BETTER PROTECTION AGAINST DAMAGE
- EACH AMP IS AUDIO PRECISION™ TESTED, WHICH INCLUDES A BURN-IN UNDER FULL LOAD

SPECIFICATIONS

OUTPUT POWER
1 CHANNEL RMS CONTINUOUS
- 8 OHMS: 750 WATTS
- 4 OHMS: 1225 WATTS
- 2 OHMS: 1950 WATTS
BOTH CH RMS CONTINUOUS
- 8 OHMS: 700/700 WATTS
- 4 OHMS: 1150/1150 WATTS
- 2 OHMS: 1800/1800 WATTS
BRIDGED RMS CONTINUOUS
- 8 OHMS BRIDGED: 2300 WATTS
- 4 OHMS BRIDGED: 3800 WATTS

PEAK POWER: 5000W (2 CYCLE PULSE POWER)

- FREQUENCY RESPONSE: +-.5 DB 20 HZ - 20 KHZ
- THD< 0.03% @ 50% OUTPUT, <.1% 20-20 kHz @ 90% output
- Output Topology: CLASS A/B
- Power Supply: Switchmode - 60% reserve - see kick drum test
- Damping Factor: >500
- SLEW RATE: BRIDGED MODE >50V/ΜS
- SENSITIVITY (@ 8Ω): 1.4 VRMS
- SIGNAL TO NOISE RATIO: GREATER THAN 106 DB
- INPUT IMPEDANCE: >20K OHM BALANCED
- SPEAKER GUARD™ DC PRODUCTION FOR DRIVERS
- SOFT-START POWER-UPS: PREVENTS AC BREAKERS FROM TRIPPING
- OVER-CURRENT: PROTECTED
- UNDER-VOLTAGE: PROTECTED
- THERMAL: PROTECTED
- FAN: VARIABLE SPEED
- SHOCK-PROOF SMT CONSTRUCTION
- FR4 FIRE RETARDANT CIRCUIT BOARDS
- ALUMINUM CHASSIS
- AIR FLOW - "REAR TO FRONT" FOR COOLER RACK
- AC GENERATOR FRIENDLY
- AC INPUT: 120VAC 60HZ
- FUSE: 25 AMPS
- 2RU RACKMOUNT
- DIM: 19" (48CM) WIDE X 10.5" (26.6CM) DEEP X 3.5" (9CM) HIGH
- WEIGHT: 14 LBS (6.4KG)
- MADE IN THE USA
- 3 YEAR WARRANTY


EXTRAS: N/A

MODIFICATIONS: N/A

HISTORY: IN MY RACK CASE THE WHOLE TIME, IN TOWN USAGE ONLY.

COMMENTS: N/A

THIS UNIT WAS NEVER TOURED
