CARVIN DCM3800L AMPS
[PRICED PER UNIT - 4 AVAILABLE AT TIME OF LISTING]
Listing last update on October 22, 2014 - Viewed 300 times

CARVIN DCM3800L (YOM: ?) (S#: TBD) LIKE NEW (9-10)

FEATURES:
- BUILT-IN LIMITERS HELP PROTECT DRIVERS
- LED INDICATORS: POWER, CLIP, 3 LEVELS, PROTECT, BRIDGE
- BALANCED XLR AND 1/4" INPUTS
- TWIST-LOCK OUTPUT CONNECTORS
- 3RD TWIST-LOCK CONNECTOR FOR BRIDGING
- HEAVY-DUTY OUTPUT BINDING POSTS
- REAR SWITCHES: BRIDGING, LIMITER, CHANNEL PARALLELING, GROUND LIFT
- RECESSED KNOBS OFFER BETTER PROTECTION AGAINST DAMAGE
- EACH AMP IS AUDIO PRECISION™ TESTED, WHICH INCLUDES A BURN-IN UNDER FULL LOAD

SPECIFICATIONS:

OUTPUT POWER
1 CHANNEL RMS CONTINUOUS
- 8 OHMS: 750 WATTS
- 4 OHMS: 1225 WATTS
- 2 OHMS: 1950 WATTS
BOTH CH RMS CONTINUOUS
- 8 OHMS: 700/700 WATTS
- 4 OHMS: 1150/1150 WATTS
- 2 OHMS: 1800/1800 WATTS
BRIDGED RMS CONTINUOUS
- 8 OHMS BRIDGED: 2300 WATTS
- 4 OHMS BRIDGED: 3800 WATTS

PEAK POWER: 5000W (2 CYCLE PULSE POWER)

- FREQUENCY RESPONSE: +-.5 DB 20 HZ - 20 KHZ
- THD< 0.03% @ 50% OUTPUT, <.1% 20-20 kHz @ 90% output
- OUTPUT TOPOLOGY: CLASS A/B
- POWER SUPPLY: SWITCHMODE - 60% RESERVE - SEE KICK DRUM TEST
- DAMPING FACTOR: >500
- SLEW RATE: BRIDGED MODE >50V/ΜS
- SENSITIVITY (@ 8OHMS): 1.4 VRMS
- SIGNAL TO NOISE RATIO: GREATER THAN 106 DB
- INPUT IMPEDANCE: >20K OHM BALANCED
- SPEAKER GUARD™ DC PRODUCTION FOR DRIVERS
- SOFT-START POWER-UPS: PREVENTS AC BREAKERS FROM TRIPPING
- OVER-CURRENT: PROTECTED
- UNDER-VOLTAGE: PROTECTED
- THERMAL: PROTECTED
- FAN: VARIABLE SPEED
- SHOCK-PROOF SMT CONSTRUCTION
- FR4 FIRE RETARDANT CIRCUIT BOARDS
- ALUMINUM CHASSIS
- AIR FLOW - "REAR TO FRONT" FOR COOLER RACK
- AC GENERATOR FRIENDLY
- AC INPUT: 120VAC 60HZ
- FUSE: 25 AMPS
- 2RU RACKMOUNT
- DIM: 19" (48CM) WIDE X 10.5" (26.6CM) DEEP X 3.5" (9CM) HIGH
- WEIGHT: 14 LBS (6.4KG)
- MADE IN THE USA
- 3 YEAR WARRANTY

EXTRAS: N/A

MODIFICATIONS: N/A

HISTORY:

I HAVE OWNED THESE AMPS FOR ABOUT 5 MONTHS. THEY ARE JUST LIKE NEW!! BEEN IN MY CASE THE WHOLE TIME ARE IN SUPER GREAT SHAPE!!

COMMENTS:

THIS UNIT WAS NEVER TOURED
