CREST 7301
[PRICED PER UNIT - 10 AVAILABLE AT TIME OF LISTING]
Listing last update on July 14, 2015 - Viewed 240 times

CREST 7301 (YOM: ?) (S#: TBD) SUPERB (8-9)

FEATURES: PRODUCT DESCRIPTION
THE CREST AUDIO 7301 IS A TWO RACK SPACE, COMPACT POWER AMPLIFIER SPECIFICALLY DESIGNED FOR USE IN BI-AMPLIFIED SYSTEMS, INCLUDING STAGE MONITOR, STUDIO MONITOR AND FRONT-OF-HOUSE APPLICATIONS. THE LOW FREQUENCY CHANNEL (CH. A) UTILIZES CLASS H OPERATION, WHICH INCREASES EFFICIENCY AND YIELDS HIGHER OUTPUT POWER ON THE LOW END. THE HIGH FREQUENCY CHANNEL (CH. B) UTILIZES CLASS AB OPERATION WHICH IS OPTIMIZED FOR PRECISE REPRODUCTION OF MID AND HIGH-FREQUENCY SIGNALS.
FOR BI-AMPED SYSTEMS, THE CREST AUDIO 7301 IS UNMATCHED IN QUALITY, EFFICIENCY AND SONIC ACCURACY. WHEN USED IN COMBINATION WITH A CROSSOVER (INCLUDING THOSE AVAILABLE IN THE CREST AUDIO OCTAL SOCKET ACCESSORY LINE), THE 7301 BECOMES A COMPLETE BI-AMPLIFICATION SYSTEM, IN A SPACE-EFFICIENT PACKAGE. THE 7301 IS FULLY COMPATIBLE IN DESIGN WITH THE OTHER CREST AUDIO PROFESSIONAL SERIES AMPLIFIERS, OCTAL SOCKET ACCESSORIES,.
DESIGN AND CONSTRUCTION
THE NO-COMPROMISE APPROACH IN THE 7301'S ELECTRICAL DESIGN AND MECHANICAL CONSTRUCTION PROVIDES THE ULTIMATE IN RELIABILITY AND PERFORMANCE. ONLY HIGH-GRADE COMPONENTS ARE USED FOR THE MODULAR SUB-ASSEMBLIES IN THIS ULTRA-STRONG, STEEL SINGLE PIECE CHASSIS.
P O W E R S P E C I F I C A T I O N S
HIGH FREQUENCY POWER @ 1KHZ, <0.05% THD
LOW FREQUENCY POWER @ 100HZ, <0.1% THD.
BOTH CH. @ 4Ω
940 WATTS
240 WATTS
7301 FEATURES
• CREST AUDIO'S LEGENDARY "OVERBUILT" POWER SUPPLY
• TOROIDAL POWER TRANSFORMER
• LATEST GENERATION OF HIGH-SPEED, WIDE-BANDWIDTH OUTPUT DEVICES
• TUNNEL COOLING WITH BACK-TO-FRONT AIR FLOW
• DUAL, VARIABLE SPEED DC FANS
• HIGH THERMAL MASS HEAT SINKS
• BALANCED XLR INPUTS
• 5-WAY OUTPUT BINDING POST CONNECTORS
• REAR PANEL GROUND LIFT JUMPER
• 7301 PROTECTION CIRCUITRY:
- CLIP LIMITING PREVENTS SPEAKER DAMAGE WITH GENTLE GAIN REDUCTION AT CLIP THRESHOLD.
- IGM (INSTANTANEOUS GAIN MODULATION) MONITORS CONNECTED LOADS TO DETECT CONDITIONS THAT MAY OVERSTRESS OUTPUT
DEVICES, ALLOWING SAFE OPERATION INTO NOMINAL 2Ω IMPEDANCES.
- AUTORAMP GRADUALLY INCREASES GAIN TO ATTENUATOR SETTING LEVEL WHEN AMPLIFIER IS TURNED ON.
- OTHER PROTECTION CIRCUITRY: COMPREHENSIVE THERMAL MANAGEMENT, AND SHORT CIRCUIT, DC VOLTAGE, TURN-ON/OFF TRANSIENT, CURRENT INRUSH AND SUB/ULTRASONIC INPUT PROTECTION

EXTRAS: CROSSOVER MODULE IN EACH AMP

MODIFICATIONS: NO MODIFICATIONS

HISTORY: REGIONAL USE ONLY, NO TOURING

COMMENTS: VERY CLEAN AMPLIFIERS

THIS UNIT WAS NEVER TOURED
