SERIES FIVE 56 CH FOH & SERIES 5 MONITOR 32 BUS 48CH MATCHED PAIR
[PRICE SHOWN FOR THE ENTIRE CONTENT OF THIS LISTING]
Listing last update on October 27, 2011 - Viewed 314 times

SOUNDCRAFT SERIES FIVE/SERIES FIVE MONITOR (YOM: ?) (S#: TBD) GOOD (7-8)

FEATURES: SERIES FIVE 56 CH FOH CONSOLE---------------------

OVER 25 YEARS OF SUCCESS IN MIXING CONSOLE DESIGN AND MANUFACTURE HAS GIVEN SOUNDCRAFT UNIQUE INSIGHT INTO THE DEMANDS OF LEADING AUDIO PROFESSIONALS. THROUGH THE APPLICATION OF THIS EXPERIENCE, AND HAVING SOUGHT THE OPINIONS OF TOP LIVE SOUND ENGINEERS AND DESIGNERS, SOUNDCRAFT HAS ARRIVED AT WHAT IT STRONGLY BELIEVES TO BE ITS BEST FRONT OF HOUSE CONSOLE YET. SOUNDCRAFT SET OUT TO PROVIDE A GREAT-SOUNDING, FULLY-FEATURED AND AFFORDABLE LIVE SOUND CONSOLE. THE RESULT IS THE SERIES FIVE.

AVAILABLE IN FRAME SIZES OF 24 TO 56 INPUT CHANNELS, SERIES FIVE IS IDEALLY SUITED TO A WHOLE RANGE OF DEMANDING APPLICATIONS FROM TOURING TO THEATRE INSTALLATION. SERIES FIVE’S COMPREHENSIVE STANDARD FEATURE SET INCLUDES LCR PANNING, AUX MASTER LEVELS ON 100MM FADERS, FULL-SPEC STEREO MODULES AND FX RETURNS, PLUS FLEXIBLE MIDI SCENE CONTROL. DESPITE THE SERIES FIVE'S HIGH LEVEL OF FACILITIES, THE CONSOLE'S LAYOUT IS CLEAR AND REASSURINGLY FAMILIAR. THIS HAS BEEN ACHIEVED WITHOUT COMPROMISING THE AUDIO QUALITY.


KEY FEATURES


24-56 CHANNEL FRAME SIZES
4 STEREO MIC / LINE INPUTS WITH FULL EQ AS STANDARD
RUGGED POWER SUPPLY WITH THREE YEAR WARRANTY
8 SUB-GROUPS
12 AUXILIARY BUSSES
10 VCA GROUPS
BUILT-IN 16X10 OUTPUT MATRIX
4-BAND FULLY PARAMETRIC EQ ON BOTH MONO AND STEREO INPUTS
SWEEPABLE FILTERS ON ALL INPUT CHANNELS
INPUT METERING ON EVERY CHANNEL
VU OUTPUT METERBRIDGE INCLUDED AS STANDARD
8 MUTE GROUPS PLUS 256 MIDI CONTROLLABLE SNAPSHOTS OF ALL INPUT AND OUTPUT MUTES
MIDI PROGRAM CHANGE TRANSMISSION AND DATAFADER CONTINUOUS CONTROLLER
SWITCHABLE LCR PANNING AS STANDARD
COMPACT, LIGHTWEIGHT FRAME DESIGNED TO WITHSTAND TOURING

SERIES FIVE MONITOR 32 BUS 48 CH------------------

SERIES FIVE MONITOR IS A DEDICATED MONITOR MIXING CONSOLE DESIGNED TO MEET THE EXACTING REQUIREMENTS OF TODAY’S MAJOR TOURS AND INSTALLATIONS. WITH INPUT CHANNELS BOASTING A FEATURE SET SIMILAR TO THAT OF THE HIGHLY-RESPECTED FIVE FRONT-OF-HOUSE CONSOLE, FIVE MONITOR OFFERS AN EQUALLY HIGH LEVEL OF CONTROL OVER STAGE SOURCES AS ITS BROTHER, BUT ADDS TO THIS THE COMPREHENSIVE ROUTING AND OUTPUT CONTROL REQUIRED FROM A MONITOR CONSOLE. IN RESPONSE TO THE DEMAND FOR LARGER, MORE COMPLEX OUTPUT CAPABILITY, FIVE MONITOR IS AVAILABLE IN TWO FRAME TYPES - 24-BUS AND 32-BUS. THE 24-BUS VERSION INCLUDES AS STANDARD A 23 X 12 OUTPUT MATRIX, GIVING AN IMPRESSIVE MAXIMUM OUTPUT CAPABILITY OF 38 BALANCED OUTPUTS. THE 32-BUS FRAME HAS AS STANDARD A 23 X 16 OUTPUT MATRIX, MAKING A MASSIVE TOTAL OF 50 BALANCED OUTPUTS. THE PROLIFERATION OF STEREO KEYBOARD OR SUBMIX SOURCES, IN ADDITION TO THE TREND TOWARDS IN-EAR MONITORING, MEANS THAT STEREO OUTPUT CAPABILITY IS NOW NO LONGER A LUXURY OPTION: BOTH FIVE MONITOR FRAME TYPES SUPPORT STEREO OUTPUTS - 9 STEREO ON THE 24- BUS, AND 17 STEREO ON THE 32-BUS CONSOLE.
THE 24-BUS CONSOLE IS AVAILABLE WITH 44, 52 OR 60 INPUT CHANNELS. THE 32-BUS CONSOLE IS AVAILABLE WITH 40, 48 OR 56 INPUT CHANNELS.

FOR THOSE SITUATIONS WHICH DEMAND THAT OUTPUTS FEED A COMBINATION OF DIFFERENT SYSTEMS (WEDGES, IN-EAR), THE FIVE MONITOR OFFERS TWO SOLO SYSTEMS - REGULAR SOLO AND ALT SOLO. VIA A SIMPLE SWITCH ON THE OUTPUTS, EACH GROUP AND MATRIX OUTPUT BUS MAY BE SET TO SEND TO EITHER OF THESE SOLO SYSTEMS, MAKING SETUP OF ACCURATE SOLO CONFIGUR-ATIONS (PERHAPS A MAIN WEDGE ON SOLO, AND AN ENGINEER IN-EAR SET ON ALT SOLO) A SIMPLE TASK.

IN ADDITION, VIA A SPECIAL PAIR OF AUXILIARY MIDI PORTS, THE FIVE MONITOR CAN SEND MESSAGES TO A BSS FPC-900 VARICURVE REMOTE CONTROLLER OR DBX DRIVERACK TO SELECT PARTICULAR SLAVE EQ DEVICES IN A RACK WHENEVER A FIVE MONITOR OUTPUT SOLO IS ACTIVATED. THIS ACCELERATES CONSIDERABLY THE PROCESS OF SOLOING AND EDITING AN OUTPUT EQ. OF COURSE, ALL OF THIS IS PACKAGED IN THE RUGGED, ROAD-PROVEN FRAME OF THE FIVE, DESIGNED TO KEEP WEIGHT AND SIZE TO A MINIMUM WITHOUT SACRIFICING MECHANICAL INTEGRITY. THE PACKAGE IS COMPLETED BY THE ADDITION OF THE SAME ACCLAIMED ALL-NEW FIVE POWER SUPPLY DESIGN - THE CPS2000, FEATURING BUILT-IN REDUNDANCY LINK, INDUSTRY STANDARD LINEAR CIRCUIT DESIGN AND PLENTY OF HEADROOM.


EXTRAS: COMES WITH ROAD CASES FOR BOTH BOARDS, ROAD CASES HAVE WHEELS.

MODIFICATIONS: FREE DELIEVERY WITH IN 500 MILES OF SPOKANE, WA.

HISTORY: BEEN USED IN CONJUNCTION WITH A PA/BACKLINE COMPANY IN BUSINESS FOR 30 YEARS.

COMMENTS: THESE BOARDS WERE TESTED BEFORE THE LISTING, AND ARE IN FULL WORKING ORDER.

THIS UNIT WAS NEVER TOURED
