EAW UX8800 DIGITAL SIGNAL PROCESSOR
[PRICED PER UNIT - 4 AVAILABLE AT TIME OF LISTING]
Listing last update on November 16, 2016 - Viewed 145 times

EAW UX8800 (YOM: 2010) (S#: TBD) LIKE NEW (9-10)

FEATURES: THESE EAW UX8800 DIGITAL SIGNAL PROCESSORS ARE FROM OUR RENTAL INVENTORY, AND ARE IN GOOD WORKING ORDER. SOME SLIGHT RACK RASH FROM USE, BUT IN OVERALL EXCELLENT CONDITION.

TWO OPERATIONAL MODES:
SYSTEM PROCESSOR – ALL SIGNAL PROCESSING IS USER-ADJUSTABLE.
LOUDSPEAKER PROCESSOR – PRESET SIGNAL PROCESSING FOR EAW LOUDSPEAKERS WITH GUNNESS FOCUSING™ TO OPTIMIZE PERFORMANCE.
COMPREHENSIVE, INTUITIVE FRONT PANEL CONTROL MAKES COMPUTER CONTROL UNNECESSARY FOR MOST ADJUSTMENTS.
U-NET – EAW-DESIGNED SIGNAL AND CONTROL NETWORKING BETWEEN UX8800S AND OTHER U-NET ENABLED PRODUCTS.
DIGITAL INPUTS TO REDUCE A/D & D/A STAGES.
EAWPILOT SOFTWARE FOR COMPREHENSIVE COMPUTER CONTROL.
FILTER PARAMETERS ARE COMPATIBLE WITH EAW’S MODELING AND ALIGNMENT SOFTWARE FOR OPTIMIZED PERFORMANCE.

INPUTS(4X)
ANALOG MODE TYPE: ELECTRONICALLY BALANCED
CONNECTOR: 4X XLR FEMALE
IMPEDANCE: 20K OHM(BALANCED), 10K OHM (UNBALANCED)
CMR: 80 DB, 1 KHZ >50 DB, 30 HZ TO 20 KHZ
CROSSTALK: -110 DB, 1 KHZ
MAXIMUM LEVEL: 18 DBU, 6.2 V
ANALOG TO DIGITAL CONVERTERS: (4X)
RESOLUTION/SAMPLING: 24 BIT, 48 KHZ
DIGITAL MODE TYPE: AES/EBU TRANSFORMER AND DC ISOLATED
CONNECTOR: 2X XLR FEMALE
IMPEDANCE: 110 OHM
NOMINAL LEVEL: 2 V TO 7 V PEAK-TO-PEAK
SAMPLING RATES: 44.1 KHZ, 48 KHZ, 88.2 KHZ, 96 KHZ 1
U-NET DIGITAL TYPE: PROPRIETARY 32 CHANNEL
CONNECTOR: 2X RJ-45
SAMPLING RATES: 44.1 KHZ, 48 KHZ, 88.2 KHZ, 96 KHZ 1
OUTPUTS
(8X)
ANALOG TYPE: ELECTRONICALLY BALANCED
CONNECTOR: 8X XLR MALE
IMPEDANCE: <50 ohm
Crosstalk: -115 dB, 1 kHz
Max Level: 18 dBu, 6.2 V @ >600 OHM LOAD
ABSOLUTE MIN LOAD: >50 OHM / 20 NF)
DIGITAL TO ANALOG CONVERTERS: (8X)
RESOLUTION/SAMPLING: 24 BIT, 48 KHZ
U-NET DIGITAL TYPE: PROPRIETARY 32 CHANNEL
CONNECTOR: 2X RJ-45
SAMPLING RATE: 48 KHZ
DIGITAL PROCESSING
PROCESSOR: 50 MFLOP, 32 BIT, 48 KHZ SHARC
LATENCY: 3.13 MS
NETWORKING
(COMMUNICATION / CONTROL)
TYPE: ETHERNET (10/100 MBPS) 1X RJ-45 FRONT PANEL
U-NET: U-NET 2X RJ-45 REAR PANEL
NETWORK PROTOCOLS: TCP/IP STATIC / DYNAMIC
CONTROL SOFTWARE: EAWPILOT


EXTRAS: NO EXTRAS

MODIFICATIONS: NO MODIFICATIONS

HISTORY: THESE UNITS ARE LIKE NEW, HAVE ALWAYS BEEN RACKED.

COMMENTS: NO ISSUES WITH THESE UNITS

THIS UNIT WAS TOURED
