D.W. FEARN VT-15 CHANNEL STRIP - EXTREMELY RARE - ONLY 25 WERE MADE
[PRICED PER UNIT - 1 AVAILABLE AT TIME OF LISTING]
Listing last update on November 21, 2013 - Viewed 433 times

D.W. FEARN VT-15 (YOM: 2008) (S#: 007) LIKE NEW IN ORIGINAL PACKAGING (10)

FEATURES: MIC PREAMP

THE MIC PREAMP SECTION HAS ALL THE FEATURES OF THE VT-1 (THE SINGLE-CHANNEL VERSION OF THE VT-2), PLUS A BUILT IN LINE PAD (THE SAME AS OUR LP-1), AND A FRONT-PANEL 1/4” JACK FOR AN INSTRUMENT INPUT FROM AN ELECTRIC OR ELECTRONIC GUITAR OR KEYBOARD.

COMPRESSOR

THE COMPRESSION SECTION IS IDENTICAL TO A SINGLE CHANNEL OF THE VT-7 STEREO COMPRESSOR, INCLUDING A SWITCHABLE HIGH-PASS FILTER IN THE SIDECHAIN TO REDUCE LOW FREQUENCY COMPRESSION WHEN NECESSARY.

EQUALIZER

THE EQUALIZATION SECTION IS A SCALED-DOWN VERSION OF THE VERSATILE VT-4 LC EQUALIZER. IT HAS A SINGLE FREQUENCY FOR EACH OF THE LF BOOST, LF CUT, HF BOOST, AND HF CUT. THESE FREQUENCIES WERE DETERMINED BY ANALYZING WHICH WERE THE MOST OFTEN USED SETTINGS ON THE VT-4. APPROXIMATE EQUALIZATION FREQUENCIES: LF BOOST 100HZ, SHELVING; LF CUT 90HZ, SHELVING; HF BOOST 9.8KHZ, WITH ADJUSTABLE Q; HF CUT 11KHZ, SHELVING. THE CONTROLS ARE CONTINUOUSLY VARIABLE, FROM -12DB OF CUT TO +12DB OF BOOST. THE HF Q IS ALSO CONTINUOUSLY VARIABLE.

WHICH COMES FIRST, COMPRESSION OR EQUALIZATION?

SOMETIMES YOU NEED THE COMPRESSION BEFORE THE EQ, AND SOMETIMES THE EQ SHOULD COME FIRST. THE VT-15 DOES NOT LOCK YOU INTO ONLY ONE CONFIGURATION; A FRONT PANEL SWITCH ALLOWS YOU TO INSTANTLY SWITCH FROM COMP/EQ TO EQ/COMP.

A FULL-SIZE TRUE VU METER MONITORS EITHER GAIN REDUCTION OR OUTPUT LEVEL. THE MIC/LINE INPUT CONNECTOR IS A XLR FEMALE, AND THE OUTPUT IS A XLR MALE, BOTH ON THE BACK PANEL. THE INSTRUMENT INPUT IS A QUARTER-INCH JACK ON THE FRONT PANEL. THE VT-15 IS IN A STANDARD RACK-MOUNT PACKAGE, 5.25” HIGH (3RU). A REAR PANEL SWITCH ALLOWS THE VT-15 TO INSTANTLY BE CONVERTED FROM 120 TO 240VAC OPERATION, 50/60HZ.

EXTRAS: SHIPPED IN ORIGINAL PACKAGING WITH ALL MANUALS AND CERTIFICATIONS.

MODIFICATIONS: NONE.

HISTORY: I AM THE SECOND OWNER. THIS UNIT WAS ORIGINALLY SOLD TO A BOUTIQUE RECORDING STUDIO. THE UNIT WAS TRADED IN FOR CREDIT ON TWO OF THE FEARN COMPRESSORS. IT WAS RE-CERTIFIED "AS NEW" BY DOUG FEARN HIMSELF IN NOVEMBER OF 2013.

COMMENTS: THIS UNIT IS IN FLAWLESS, "AS NEW" CONDITION.

THIS UNIT WAS NEVER TOURED
