MEDIAMATRIX CAB 16I
[PRICE SHOWN FOR THE ENTIRE CONTENT OF THIS LISTING]
Listing last update on August 02, 2011 - Viewed 346 times

MEDIAMATRIX CAB 16I INPUT MODULE W/COBRANET - SERIAL# 51733285


THE CAB 16I IS A 16-CHANNEL, LINE LEVEL, INPUT ONLY DEVICE USING 24-BIT ANALOG-TO-DIGITAL CONVERTERS.

PRODUCT FEATURES:
FOUR 16-POSITION FRONT PANEL ROTARY SWITCHES FOR UNIT ID
FRONT PANEL LEVEL METER FOR EACH CHANNEL
24-BIT QUANTIZATION 64X OVERSAMPLING
48 KHZ SAMPLE-RATE
SUPPORTS RS-485 BRIDGING
WORD CLOCK FOR SYSTEM REDUNDANCY 釘UDDY LINK
ADVANCED AUDIO ROUTING WHEN INTEGRATED WITH MEDIAMATRIX
UNIVERSAL POWER SUPPLY (100-240V 50-60 HZ)

PRODUCT SPECIFICATIONS
SIXTEEN CHANNELS OF LINE-LEVEL AUDIO TRANSMITTED ONTO AN ETHERNET NETWORK
COBRANET PROTOCOL SAMPLED AT 48 KHZ
A/D CONVERTERS ARE 24-BIT 64 TIMES OVERSAMPLING, USING DELTA-SIGMA MODULATION
24, 20, OR 16-BIT TRANSMISSION QUANTIZATION AT A 48 KHZ SAMPLING RATE.
LOW NOISE/WIDE DYNAMIC RANGE 108 DB TYPICAL
A NON-ETHERNET RS-485 CONTROL PORT WITH TWO MULTI-DROP CONNECTIONS.
TWO WORD CLOCK LINKING CONNECTORS THAT ENABLE AUTO-SWITCH-OVER TO A SECOND UNIT, SHOULD ONE UNIT FAIL.
ONE RACK-UNIT (1-3/4")
FAN-COOLED CHASSIS.

HTTP://MM.PEAVEY.COM/PRODUCTS/PRODUCT.CFM?ITEM_ID=32
