(29) ELATION | EVLED 256 | 37MM VIDEO PANELS
[PRICE SHOWN FOR THE ENTIRE CONTENT OF THIS LISTING]
Listing last update on March 21, 2015 - Viewed 266 times

ELATION EVLED 256 (YOM: 2012) (S#: TBD) SUPERB (8-9)

FEATURES: THIS LISTING IS FOR (29) EXTREMELY WELL TAKEN CARE OF ELATION EVLED 256 VIDEO PANELS, ALL PANELS ARE IN COMPLETE WORKING ORDER AND ARE READY FOR MANY YEARS OR WORRY FREE OPERATION.

BELOW IS THE MANUFACTURES DESCRIPTION:

37.5MM PITCH - LIGHT WEIGHT TRANSPARENT LED VIDEO SCREEN

• PIXEL PITCH : 37.5 MM (1.5")
• TRANSPARENCY: 55%
• CURTAIN COMPOSITION: AL-ALLOY FRAME
• ELECTRONICS ONBOARD W/ RUBBER GASKET FOR WEATHERPROOF IP 65 RATING
• TILE SIZE: 600 X 600 X 75 MM/TILE (2 X 2)
• TILE WEIGHT: 4.5 KG/TILE (10LBS.)
• TILE AREA: 0.36M2/TILE• LUMINOSITY: 2000 NITS
• COLOR TEMPERATURE: 6500 K
• VISUAL ANGLE 110 / 50° (50% BRIGHTNESS)
• VISUAL RANGE: 160 / 120°
• PIXEL CONFIGURATION: 1R 1G 1B (DIP)
• TILE RSOLUTION: 16 X 16 PIXELS/TILE
• PIXEL RESOLUTION: 711 PIXELS/M2
• LED QUANTITY: 2133 LEDS/M2
• COLOR NUMBER: 14 TRILLION
• PROCESSING DEPTH: 14 BITS
• CONTRAST RATION: 2,000:1
• LIFE SPAN: 100,000 HOURS - LED: 50,000-70,000 HOUR
• FRAME RATE : 60HZ
• DATA REFRESH RATE: 800HZ
• DISPLAY MODE: SYNCHRONOUS WITH VIDEO SOURCE
• LED FAILURE RATE: 1/10,000
• MTBF: > 10,000 HOURS
• DRIVE MODE: STATIC, CONSTANT CURRENT DRIVE
• POWER SUPPLY: AC 100-240V, 50HZ OR 60 HZ
• WORKING VOLTAGE: DC 5V
• POWER CONSUMPTION: 60W PER PANEL
• INGRESS PROTECTION: FRONT: IP65, BACK: IP65
• AMBIENT TEMPERATURE: -20 TO +50 CELSIUS DEGREE
• RELATIVE HUMIDITY: 10% TO 99%

EXTRAS: FLIGHT CASES FOR (24) PANELS INCLUDED, RIGGING CABLES & BRACKETS ALSO INCLUDED, IMAGE PROCESSOR CAN BE INCLUDED FOR AN ADDITIONAL FEE.



MODIFICATIONS: NO MODIFICATIONS

HISTORY: MAINLY CORPORATE USE

COMMENTS: READY FOR WORK

THIS UNIT WAS NEVER TOURED
